PVC electrical tape insulation tape high temperature resistant anti-corrosion coating machine manufacturers in Suzhou

First, the use of

The introduction of foreign advanced coater technology combined with comprehensive experience of their years of production coating machine, and, this machine use comma scraper and netted two coating, comma blade coating for tape glue coating, reseaus coating for coated with silicone oil, widely used in the production of aluminum foil adhesive belt, kraft paper tape, BOPP tape, from paper, from type membrane coated products.

1. The machine adopts five inverter motor control, machine tension (unwinding, coating, drawing and winding) by Japan's Mitsubishi brand PLC system automatic control, through the man-machine interface touch screen control and display and improve the reliability of the whole machine tension.

2 the discharge frame is a hydraulic lifting single station, which is controlled by magnetic powder automatic tension.

3. Comma doctor roll clutch adjusting the pneumatic swing arm type, swing arm equipped with micro adjustment device, adhesive thickness by feeler control.

4. Textured coating method, coating blade axis adopts independent type biaxial mechanical swimming, scraper regulation for manual with pneumatic, arbitrary angle adjustment, coating was determined in roller mesh line, different amount of coating can be for different target line roller.

5 oven for 18 meters in 9 separate temperature control, heating with heat conduction oil circulation heating, hot air into the type drying system, adjustable internal circulation suction and exhaust device, inlet, exhaust wind strong, dry completely.

Active synchronization with the host using a 6. The oven inner guide wheel, drive by synchronous belt wheel drive type, relief material stretching and deformation, cylinder, truncated, oven and wear membrane operation platform, enable operators to facilitate the work.

7 coating roller - traction steel roller intermediate tension synchronization using the floating swing arm by the PLC automatic control

8 automatic meter speed control device

9 to rectify the use of EPC on the edge of the machine, in order to collect the volume of materials.

10 and the key sub air shaft for loading and unloading, convenient operation.

High precision pressure traction device, using circulating water cooling steel roller, by cooling and membrane more smooth, more pretty blow, more cooling effect can be reached.

12 receiving rack form is a hydraulic lifting single station, the volume of the use of variable frequency motor, vector inverter controlled by the PLC computer system.

Four, requirements

A, according to the different requirements of customers special custom machine (limited width range of 300-2000mm)

B, retractable rack respectively: manual lifting type single station, hydraulic lifting type single station, electric turning double station, electric zipper climbing type double station, electric turning wheel type double stations for the customer to choose

C, oven heating conditions are: electric heating, steam heating, heating furnace for customers to choose

D, coating: coating roller, double roll coating, and coating, and coating, comma blade coating, air knife coating for customers to choose

E, the work speed and coating material, coating thickness, oven length, drying temperature and so on.

Five, process flow

Substrate roll up - coating unit - drying unit - traction unit - roll up machine
